Model-to-model transformation: SL2FUN converts Simulink-models into a functional reference model based on XML. SL2FUN generates a reference model out of the most complex Simulink models and resolves distributed libraries.

  • enables the automatic migration of huge, complex Simulink-models and libraries to any PDM/PLM system as well as the migration to other modelling tools.
  • SL2FUN transforms Simulink-models and libraries into XML-code. You get one integrated functional model. In addition the tool generates a type library with reusable function blocks. The types are instanciated in the functional model.
  • The original Simulink-models are split into pieces that can be handled by data management systems.
  • SL2FUN resolves stacked libraries (no limitations in layers)
  • The XML code includes all the important information but not all the unused format information that Simulink normally stores with the models.
  • The output of the tool can be converted into a format that can be read by authoring tools and PDM/PLM-systems.
  • It is also possible to generate Simulink-models out of the model that is generated by the tool.


Coming next:

    • optimisation of the models during transformation and reduction in size.
    • Generation of the fault matrix for fault back tracking and failure effects analysis out of existing Simulink models.
    • Parameter extraction: handling of parameters including those which are hidden in blocks
    • Connectors to PDM/PLM systems



Format converter, converts the XML-output of SL2FUN into ESCAPE format



Connector to Teamcenter (please contact us)


Connector to CATIA  (please contact us)


Connector to DS2  (please contact us)


Connector to Windchill  (please contact us)


Stuck in the complexity trap?

Huge effort for model management?

Here is the solution!

- Clean up your Simulink models and libraries

- Migrate complex models and libs to PDM/PLM

- Reduce model size and code generation time

- Master complexity!
